Awovolift Chipboard Panels Vacuum Lift Tube Lifting Box Pneumatic air Tube Lifter Premium Quality Vacuum Lift for Bag 100kg

Product Parameter

Vacuum Lift Tube
Assembly Set Number
Dimensions Load
Liftcm Extended HeightHE
cm
Compressed HeightHC
cm
Non-Porous Loads
kg
Semi-Porous Loads
kg
Porous Loads
kg
AL-VT80-A 167 280 112 23 16 14
AL-VT100-A 167 275 108 43 32 23
AL-VT120-A 167 277 110 64 48 32
AL-VT140 167 277 110 84 64 43
AL-VT160 167 282 115 102 77 52
AL-VT180 167 287 120 129 98 66
AL-VT200 167 287 120 161 120 80
AL-VT230 167 287 140 214 160 107
AL-VT250 167 292 124 230 175 125
AL-VT300 167 292 124 250 195 140

Product Description

Vacuum Tube Lifters - A Versatile Load Handling System

Vacuum tube lifters are a unique lifting aid designed for repetitive handling ofmaterials or loads that are breakable or fragile (loads not suited for grippers orgrabbing) such as concrete blocks, bags, or cardboard boxes. A tube liftsystem increases productivity while offering an ergonomic solution to materialhandling needs.

These systems hold, lift, and lower the load all with a singleoperator control, and require minimal operator training. The use of inter-changeable attachments allows for a variety of shaped and sized loads to behandled without the need for multiple systems.
